The Arduino software includes a serial monitor which allows simple textual data to be sent to and from the Arduino board via a USB connection.Ī SoftwareSerial library allows for serial communication on any of the Pro Mini's digital pins. The ATmega328P provides UART TTL serial communication, which is available on digital pins 0 (RX) and 1 (TX). The Arduino Pro Mini has a number of facilities for communicating with a computer, another Arduino, or other microcontrollers. Typically used to add a reset button to shields which block the one on the board. Bring this line LOW to reset the microcontroller. Support I2C (TWI) communication using the Wire library. Additionally, some pins have specialized functionality: The analog inputs measure from ground to VCC. Four of them are on the headers on the edge of the board two (inputs 4 and 5) on holes in the interior of the board. The Pro Mini has 8 analog inputs, each of which provide 10 bits of resolution (i.e. When the pin is HIGH value, the LED is on, when the pin is LOW, it's off. There is a built-in LED connected to digital pin 13. These pins support SPI communication, which, although provided by the underlying hardware, is not currently included in the Arduino language. Provide 8-bit PWM output with the analogWrite function. See the attachInterrupt function for details. These pins can be configured to trigger an interrupt on a low value, a rising or falling edge, or a change in value. These pins are connected to the TX-0 and RX-1 pins of the six pin header.

Used to receive (RX) and transmit (TX) TTL serial data. In addition, some pins have specialized functions: Each pin can provide or receive a maximum of 40 mA and has an internal pull-up resistor (disconnected by default) of 20-50 kOhms. They operate at 3.3 or 5 volts (depending on the model). Input and OutputĮach of the 14 digital pins on the Pro Mini can be used as an input or output, using pinMode, digitalWrite, and digitalRead functions. It has 2 kB of SRAM and 1kBs of EEPROM (which can be read and written with the EEPROM library.
#COMMENT REGLER SAFEIP PRO CODE#
The ATmega328P has 32 kB of flash memory for storing code (of which 0.5kB is used for the bootloader). RAW For supplying a raw voltage to the board. If you're supplying unregulated power to the board, be sure to connect to the "RAW" pin on not VCC. There is a voltage regulator on board so it can accept voltage up to 12VDC. The Arduino Pro Mini can be powered with an FTDI cable or breakout board connected to its six pin header, or with a regulated 3.3V or 5V supply (depending on the model) on the Vcc pin. On the Product itself through our Customer SupportĪrduino Pro Mini is open-source hardware! You can build your own board using the following files:.You can find in the Getting Started section all the information you need to configure your board, use the Arduino Software (IDE), and start tinker with coding and electronics. You can find here your board warranty information.

The Arduino Pro Mini was designed and is manufactured by SparkFun Electronics. One runs at 3.3V and 8 MHz, the other at 5V and 16 MHz. The pin layout is compatible with the Arduino Mini. The board comes without pre-mounted headers, allowing the use of various types of connectors or direct soldering of wires. The Arduino Pro Mini is intended for semi-permanent installation in objects or exhibitions. A six pin header can be connected to an FTDI cable or Sparkfun breakout board to provide USB power and communication to the board. It has 14 digital input/output pins (of which 6 can be used as PWM outputs), 6 analog inputs, an on-board resonator, a reset button, and holes for mounting pin headers. The Arduino Pro Mini is a microcontroller board based on the ATmega328P.
